Qhuav / ntub pob zeb diamond Core Laum khoom
1 Product Description
Feem ntau thaum peb laum qhov hauv pob zeb, peb yuav tsum tau siv cov tho qhov ntub dej, vim tias qhov chaw siv nyob rau lub sijhawm no feem ntau yog cov khoom siv pob zeb ua cov khoom lag luam nrog cov dej txaus. Nyob rau hauv lub tshav pob ntawm engineering siv, qhuav laum khoom yog siv rau drilling qhov nyob rau hauv pob zeb.
Cov khoom siv ntub dej thiab cov khoom siv tho qhuav yog tsim los ntawm kev siv cov xwm txheej, thiab tsis muaj qhov sib txawv kiag li. Ntxiv dej rau ib qho kev xyaum qhuav yuav ua rau nws lub neej ua haujlwm tau zoo. Qee qhov kev xyaum ntub dej tsis tuaj yeem siv rau qhov ziab qhuav. Nws kuj tseem tuaj yeem tho qhov rau lub sijhawm luv luv yam tsis muaj dej ntxiv. Piv txwv li, thaum drilling qhov rau cua txias ducts, kev ua hauj lwm feem ntau tsis siv sij hawm ntev thiab peb yuav siv ib tug qhuav xyaum me ntsis. Yog tias ua tau, nws raug nquahu kom tus neeg siv ntxiv dej, lossis dej me me.
Kev siv cov khoom sib txawv ntawm cov laum zoo tuaj yeem ua rau muaj txiaj ntsig zoo thiab kev siv nyiaj ntawm pob zeb diamond laum khoom. Nws tsis yog tias cov pob zeb diamond laum uas kim dua yog qhov zoo dua, cov sijhawm sib txawv xav tau cov khoom sib txawv los ua kom zoo tshaj plaws ntawm cov cuab yeej siv.
2 Cov khoom specification
Peb lub tuam txhab tsim thiab muab pob zeb diamond ntub laum khoom thiab pob zeb diamond qhuav laum khoom rau ntau lub hom phiaj.
Cov pob zeb zoo nkauj pob zeb diamond me ntsis tsim thiab tsim los ntawm peb lub tuam txhab siv cov yeeb nkab zoo steel los ua kom lub cev me ntsis hnav-tiv taus. Lub cev ntawm lub ntsis txais CNC drilling, nrog cov neeg siab thiab zoo concentricity. Nws tuaj yeem siv rau hauv ob qho tib si qhuav thiab ntub dej, nrog cov hnab plua plav. Kev tsim kho ib puag ncig yog huv thiab huv, tsis muaj hmoov av tsawg. Nws tau qhuas heev los ntawm cov neeg siv European thiab Asmeskas.
|
Txoj kab uas hla |
Ntu Loj |
Ntu No. |
|
7/8 "(22mm) |
16x3.0x10 |
3 |
|
1 "(25mm) |
16x3.0x10 |
4 |
|
1.18 "(29 hli) |
16x3.0x10 |
4 |
|
1.25 "(32mm) |
16x3.0x10 |
4 |
|
1.38 "(35mm) |
16x3.0x10 |
4 |
|
1.50 "(38mm) |
16x3.0x10 |
5 |
|
1.63 "(42mm) |
16x3.0x10 |
5 |
|
1.75 "(45mm) |
16x3.0x10 |
6 |
|
1.88 "(48 hli) |
16x3.0x10 |
6 |
|
2 "(52mm) |
16x3.0x10 |
7 |
|
2.25 "(57mm) |
22x3.5x10 |
5 |
|
2.50 "(63 hli) |
22x3.5x10 |
6 |
|
2.75 "(70mm) |
22x3.5x10 |
7 |
|
3" (76mm) |
22x3.5x10 |
8 |
|
3.25 "(82mm) |
22x3.5x10 |
9 |
|
3.50 "(89mm) |
22x3.5x10 |
10 |
|
4 "(102mm) |
22x3.5x10 |
10 |
|
4.25 "(108mm) |
22x3.5x10 |
11 |
|
4.50 "(114 hli) |
22x3.5x10 |
11 |
|
4.75 "(120mm) |
24x4.0x10 |
11 |
|
5 "(127mm) |
24x4.0x10 |
11 |
|
5.5 "(140mm) |
24x4.0x10 |
12 |
|
5.75 "(146mm) |
24x4.0x10 |
13 |
|
6 "(152mm) |
24x4.0x10 |
13 |
|
6.25 "(159mm) |
24x4.0x10 |
14 |
|
6.5 "(165mm) |
24x4.0x10 |
15 |
|
7" (178 hli) |
24x4.0x10 |
16 |
|
8" (203 hli) |
24x4.5x10 |
18 |
|
9" (229 hli) |
24x4.5x10 |
20 |
|
10 "(254mm) |
24x4.5x10 |
23 |
|
11 "(280mm) |
24x5.0x10 |
25 |
|
12 "(305mm) |
24x5.0x10 |
27 |
|
13 "(330mm) |
24x5.5x10 |
30 |
|
14 "(356mm) |
24x5.5x10 |
32 |
* Rau pob zeb diamond laum cov khoom nrog diameters tshaj 400, lub voj voog customization ntev dua. Thov hu rau peb cov neeg ua haujlwm pabcuam rau cov neeg siv khoom kom paub meej.
3 Cov khoom ntim khoom
Inner ntim: corrugated ntawv thawv ntim
Ntim Ntim: Ntoo thawv ntim
Customizable ntawv thawv raws li tus neeg siv xav tau
4o mus
Peb lub tuam txhab muaj ntau tshaj 20 lub siab tsis siv neeg kub xovxwm tshuab, ntau yam txias xovxwm tshuab, sib tov tshuab, thiab ntau tshaj 10 teev ntawm cov tshuab txiav. Ua tau sai thiab ua tau zoo ua tiav cov haujlwm ntau lawm.
Cim npe nrov: qhuav / ntub pob zeb diamond tub ntxhais laum khoom, Tuam Tshoj qhuav / ntub pob zeb diamond tub ntxhais laum khoom manufacturers
